Part Number: H-3020W-CS-WT / Vendor ID #: 16
Ocularc 3020W - 5CCT Wall Wash Track Luminaire
by WAC US
$302.85
Item Sales Info
Add To Wishlist
Compare Item
Email
Print
Availability
- Manufacturer has 215 items available.
Dimensions
Height: 7.88"
Width: 5.00"
Included Items
Finish: white
Ocularc H-3020W 5CCT White
Ideal for residential spaces and lower-mounted commercial installations, the OCULARC 3020W-CS provides an asymmetrical optical distribution suited to wall wash applications. Constructed from die-cast aluminum, the fixtures offer a 350-degree horizontal rotation and 90-degree vertical tilt for precision aiming. Engineered with integral 5CCT selectable LEDs and driver, it produces a high output asymmetric distribution in 90CRI. Available in monopoint or H, J/J2, and L track configurations.
Category:
Track Ltg.
Subcategory:
Track Heads
Finish:
White
Style:
Functional
Style:
Functional
Collection:
Ocularc
Voltage:
120 VAC
Bulb Dimmable:
Yes
Bulb Hours:
50000
Bulb Type:
LED
Length:
3.625
Material:
Die-cast aluminum
Ship Carton Height:
6
Ship Carton Length:
8
Ship Carton Width:
6
Warranty:
5 Year
Weight:
2
Beam Spread:
Asym
Brand:
WAC Lighting
Bulb Base:
LED Module
Bulbs Included:
Yes
Color Rendering Index:
90
Color Temperature:
2700K/3000K/3500K/4000K/5000K
Complete System:
No
Country of Origin:
China
Delivered Lumens:
1150
LTL:
No
Main Type:
Track Lighting
Manufacturers Link:
https://www.waclighting.com/?s=H-3020W-CS-WT
Number of Bulbs:
48
Number of Lights:
1
Product Sub-Type:
Low Voltage
Product Type:
H Track Fixture
Rank:
1
Release:
Jan-25
Safety Rating:
ETL, cETL
Total Wattage:
22
Watts Per Bulb:
0.46
Manufactured By:
WAC US
